Motobatt Quadflex 12V Motorcycle Battery MBTX16U Fits Triumph Bikes

MOTOBATT QUADFLEX 12V BATTERY MBTX16U

Founded in 2008, Motobatt is a manufacturer of premium Powersports batteries, battery chargers and battery related accessories. Motobatt is the creator and holds patents all over the world for the Motobatt 4 terminal battery that facilitates flexible battery installation across a wide variety of vehicles while maintaining an OE like fit.



SPECS:

• Voltage: 12V
• CCA: 250
• Capacity: 19Ah
• Weight: 5.65kg (12.5lbs)
• Dimensions (LxWxH): 151 x 87 x 161mm (5.94 x 3.43 x 6.34)
• Terminals: 2, M6x2.5 (MPT2)
• Screws: 4, M6x7 (2x MPS2)
• Allen Wrench: 1, 4x4 (MPAK2)
• Terminal Caps: 4, 12x5.5 (2x MPC2)
• Spacer: None



QUADFLEX:

Motobatt batteries are manufactured from Absorbed Glass Mat (AGM), this design has revolutionised the motorcycle, ATV, lawnmower and small engine industry. QuadFlex provides a unique four-terminal design with two positives, two negatives along with height spacers that permit an almost universal fit. All Motobatt AGM Batteries are maintenance free, non-hazardous, non-spill, charged and ready to install directly out of the box.

Each plate in the battery is wrapped in a fiberous glass matting which not only absorbs all liquid electrolyte but keeps the plates separated in a cushioned environment. This stops the plates from vibrating which can breakdown the plate and cause short circuits between the plates or break plate welds which result in battery failure. The thick, heavy plates used in Motobatt designs really make the difference.

AGM batteries also have a much lower inherent self-discharge rate than wet flooded types. And, as a higher amp hour AGM battery, the Motobatt battery can also discharge more deeply and recover repeatedly under the vehicle alternator charge or through maintenance charging. A standard flooded cell battery is not capable of withstanding this type of cycling without premature failure.

Your Motobatt is a Factory Activated battery, it comes to you pre-conditioned and fully charged for optimum performance and ready to install out of the box. 80% of early Powersports battery failure is caused by faulty activation of the dry battery plates. Additionally, you never have to mess with acid or top up fluid levels or remove corrosion from the terminals caused by gassing, which are all common with standard flooded battery types.



FEATURES:

• Patented QuadFlex multi-fit terminals
• Absorbed Glass Mat technology – ensures greater protection against vibration and gives a longer lifecycle
• Fully sealed – Can be mounted and transported in any position
• No initial charging – Install and go, charged right out of the box
• Maintenance Free – No messy acid to worry about
• 20% more cold cranking amps (CCA)
• Easy accessory connection with multiple terminals



PLEASE NOTE: Image for illustration only.



DISCLAIMER:

Battery may have lost charge due to shelf life. please charge prior to use.

Fitment Details

• Ducati 900 S2 DESMO 1983
• Ducati 900 S2 DESMO 1984
• Suzuki VS1400GL INTRUDER 1987
• Suzuki VS1400GL INTRUDER 1988
• Suzuki VS1400GL INTRUDER 1989
• Suzuki VS1400GL INTRUDER 1990
• Suzuki VS1400GL INTRUDER 1991
• Kawasaki ZR1100 ZEPHYR 1992
• Suzuki VS1400GL INTRUDER 1992
• Kawasaki ZR1100 ZEPHYR 1993
• Suzuki VS1400GL INTRUDER 1993
• Kawasaki ZR1100 ZEPHYR 1994
• Suzuki VS1400GL INTRUDER 1994
• Suzuki VS1400GL INTRUDER 1995
• Kawasaki VN1500 CLASSIC 1996
• Suzuki VS1400GL INTRUDER 1996
• Kawasaki VN1500 CLASSIC 1997
• Suzuki VS1400GL INTRUDER 1997
• Kawasaki VN1500 CLASSIC 1998
• Kawasaki VN1500 NOMAD 1998
• Suzuki LT-F500F QUADRUNNER 1998
• Suzuki VS1400GL INTRUDER 1998
• Kawasaki VN1500 CLASSIC 1999
• Kawasaki VN1500 DRIFTER 1999
• Kawasaki VN1500 NOMAD 1999
• Suzuki LT-F500F QUADRUNNER 1999
• Suzuki VL1500 INTRUDER 1999
• Suzuki VS1400GL INTRUDER 1999
• Kawasaki VN1500 DRIFTER 2000
• Suzuki LT-A500F VINSON 2000
• Suzuki LT-F500F QUADRUNNER 2000
• Suzuki VL1500 INTRUDER 2000
• Suzuki LT-A500F VINSON 2001
• Suzuki LT-F500F QUADRUNNER 2001
• Suzuki VL1500 INTRUDER 2001
• Kawasaki VN1500 MEAN STREAK 2002
• Suzuki LT-A500F VINSON 2002
• Suzuki LT-F500F QUADRUNNER 2002
• Suzuki VL1500 INTRUDER 2002
• Kawasaki VN1500 MEAN STREAK 2003
• Kawasaki VN1600 CLASSIC 2003
• Suzuki LT-A500F VINSON 2003
• Suzuki VL1500 INTRUDER 2003
• Kawasaki VN1600 CLASSIC 2004
• Kawasaki VN1600 MEAN STREAK 2004
• Kawasaki VN2000 2004
• Suzuki LT-A500F VINSON 2004
• Suzuki VL1500 INTRUDER 2004
• Suzuki VZ1600 MARAUDER 2004
• Kawasaki VN1600 CLASSIC 2005
• Kawasaki VN1600 MEAN STREAK 2005
• Kawasaki VN2000 2005
• Moto Guzzi 1100 BREVA 2005
• Moto Guzzi 1100 GRISO 2005
• Suzuki C90 BOULEVARD 2005
• Suzuki LT-A500F VINSON 2005
• Suzuki LT-A700X KING QUAD 2005
• Suzuki VZ1600 MARAUDER 2005
• Kawasaki VN1600 CLASSIC 2006
• Kawasaki VN1600 MEAN STREAK 2006
• Kawasaki VN2000 2006
• Moto Guzzi 1100 BREVA 2006
• Moto Guzzi 1100 CALIFORNIA VINTAGE 2006
• Moto Guzzi 1100 GRISO 2006
• Suzuki C90 BOULEVARD 2006
• Suzuki LT-A500F VINSON 2006
• Suzuki LT-A700X KING QUAD 2006
• Suzuki M109R VZR1800 BOULEVARD 2006
• Kawasaki VN1600 CLASSIC 2007
• Kawasaki VN1600 MEAN STREAK 2007
• Moto Guzzi 1100 CALIFORNIA VINTAGE 2007
• Moto Guzzi 1100 GRISO 2007
• Moto Guzzi 1200 NORGE 2007
• Moto Guzzi 1200 SPORT 2007
• Suzuki C90 BOULEVARD 2007
• Suzuki LT-A500F VINSON 2007
• Suzuki LT-A700X KING QUAD 2007
• Suzuki M109R VZR1800 BOULEVARD 2007
• Kawasaki VN1600 CLASSIC 2008
• Kawasaki VN1600 MEAN STREAK 2008
• Kawasaki VN1600 NOMAD 2008
• Moto Guzzi 1100 CALIFORNIA VINTAGE 2008
• Moto Guzzi 1200 NORGE 2008
• Moto Guzzi 1200 SPORT 2008
• Moto Guzzi 1200 STELVIO 2008
• Suzuki C109R BOULEVARD 2008
• Suzuki C90 BOULEVARD 2008
• Suzuki LT-A750AXI KING QUAD 2008
• Suzuki M109R VZR1800 BOULEVARD 2008
• Kawasaki VN1700 CLASSIC 2009
• Kawasaki VN1700 NOMAD 2009
• Kawasaki VN1700 VOYAGER 2009
• Moto Guzzi 1200 STELVIO 2009
• Suzuki C109R BOULEVARD 2009
• Suzuki C90 BOULEVARD 2009
• Suzuki LT-A500AXI 2009
• Suzuki LT-A750AXI KING QUAD 2009
• Suzuki M109R VZR1800 BOULEVARD 2009
• Suzuki M90 BOULEVARD 2009
• Honda XL1000V VARADERO 2010
• Kawasaki VN1700 CLASSIC 2010
• Kawasaki VN1700 NOMAD 2010
• Kawasaki VN1700 VOYAGER 2010
• Moto Guzzi 1200 STELVIO 2010
• Suzuki C109R BOULEVARD 2010
• Suzuki C90 BOULEVARD 2010
• Suzuki LT-A500AXI 2010
• Suzuki LT-A750AXI KING QUAD 2010
• Suzuki M109R VZR1800 BOULEVARD 2010
• Suzuki M90 BOULEVARD 2010
• Kawasaki VN1700 CLASSIC 2011
• Kawasaki VN1700 NOMAD 2011
• Kawasaki VN1700 VOYAGER 2011
• Moto Guzzi 1200 NORGE 8V 2011
• Suzuki C109R BOULEVARD 2011
• Suzuki C90 BOULEVARD 2011
• Suzuki C90T BOULEVARD 2011
• Suzuki LT-A500AXI 2011
• Suzuki LT-A750AXI KING QUAD 2011
• Suzuki M109R VZR1800 BOULEVARD 2011
• Triumph 800 TIGER 2011
• Triumph 800 TIGER XC 2011
• Kawasaki VN1700 CLASSIC 2012
• Kawasaki VN1700 NOMAD 2012
• Kawasaki VN1700 VAQUERO 2012
• Kawasaki VN1700 VOYAGER 2012
• Moto Guzzi 1200 SPORT 8V 2012
• Suzuki C109R BOULEVARD 2012
• Suzuki C90 BOULEVARD 2012
• Suzuki C90T BOULEVARD 2012
• Suzuki LT-A500AXI 2012
• Suzuki LT-A750AXI KING QUAD 2012
• Suzuki M109R VZR1800 BOULEVARD 2012
• Triumph 800 TIGER 2012
• Triumph 800 TIGER XC 2012
• Kawasaki VN1700 CLASSIC 2013
• Kawasaki VN1700 NOMAD 2013
• Kawasaki VN1700 VAQUERO 2013
• Kawasaki VN1700 VOYAGER 2013
• Moto Guzzi 1200 GRISO 8V 2013
• Moto Guzzi 1200 SPORT 8V 2013
• Moto Guzzi 1200 STELVIO 2013
• Suzuki C109R BOULEVARD 2013
• Suzuki C90 BOULEVARD 2013
• Suzuki C90T BOULEVARD 2013
• Suzuki LT-A500AXI 2013
• Suzuki LT-A750AXI KING QUAD 2013
• Suzuki M109R VZR1800 BOULEVARD 2013
• Triumph 800 TIGER 2013
• Triumph 800 TIGER XC 2013
• Honda TRX500FA 2014
• Kawasaki VN1700 CLASSIC 2014
• Kawasaki VN1700 NOMAD 2014
• Kawasaki VN1700 VAQUERO 2014
• Kawasaki VN1700 VOYAGER 2014
• Moto Guzzi 1200 GRISO 8V 2014
• Moto Guzzi 1200 SPORT 8V 2014
• Moto Guzzi 1200 STELVIO 2014
• Suzuki C90 BOULEVARD 2014
• Suzuki C90T BOULEVARD 2014
• Suzuki LT-A500AXI 2014
• Suzuki LT-A500FA KING QUAD 2014
• Suzuki LT-A750AXI KING QUAD 2014
• Suzuki M109R VZR1800 BOULEVARD 2014
• Triumph 800 TIGER 2014
• Triumph 800 TIGER XC 2014
• Honda TRX500FA 2015
• Kawasaki VN1700 VAQUERO 2015
• Moto Guzzi 1200 SPORT 8V 2015
• Moto Guzzi 1200 STELVIO 2015
• Suzuki C90 BOULEVARD 2015
• Suzuki LT-A500AXI 2015
• Suzuki LT-A500FA KING QUAD 2015
• Suzuki LT-A750AXI KING QUAD 2015
• Suzuki M109R VZR1800 BOULEVARD 2015
• Triumph 800 TIGER 2015
• Triumph 800 TIGER XC 2015
• Honda TRX500FA 2016
• Moto Guzzi 1200 SPORT 8V 2016
• Moto Guzzi 1200 STELVIO 2016
• Suzuki C90 BOULEVARD 2016
• Suzuki LT-A500AXI 2016
• Suzuki LT-A500FA KING QUAD 2016
• Suzuki LT-A750AXI KING QUAD 2016
• Suzuki M109R VZR1800 BOULEVARD 2016
• Triumph 1200 TIGER EXPLORER XCA 2016
• Triumph 1200 TIGER EXPLORER XCX 2016
• Triumph 800 TIGER XC 2016
• Honda TRX500FA 2017
• Suzuki C90 BOULEVARD 2017
• Suzuki LT-A500AXI 2017
• Suzuki LT-A750AXI KING QUAD 2017
• Suzuki M109R VZR1800 BOULEVARD 2017
• Triumph 1200 TIGER EXPLORER XCA 2017
• Triumph 1200 TIGER EXPLORER XCX 2017
• Triumph 800 TIGER XC 2017
• Honda TRX500FA 2018
• Suzuki C90 BOULEVARD 2018
• Suzuki LT-A500AXI 2018
• Suzuki LT-A750AXI KING QUAD 2018
• Suzuki M109R VZR1800 BOULEVARD 2018
• Triumph 1200 TIGER XCA 2018
• Triumph 1200 TIGER XCX 2018
• Triumph 800 TIGER XC 2018
• BMW R1250 RT 2019
• Honda TRX500FA 2019
• Suzuki C90 BOULEVARD 2019
• Suzuki LT-A500AXI 2019
• Suzuki M109R VZR1800 BOULEVARD 2019
• Triumph 1200 TIGER XCA 2019
• Triumph 1200 TIGER XCX 2019
• Triumph 800 TIGER XC 2019
• BMW R1250 RT 2020
• Suzuki C90 BOULEVARD 2020
• Suzuki M109R VZR1800 BOULEVARD 2020
• Triumph 1200 TIGER XCA 2020
• Triumph 1200 TIGER XCX 2020
• Triumph 900 TIGER RALLY 2020
• BMW R1250 RT 2021
• Suzuki M109R VZR1800 BOULEVARD 2021
• Triumph 900 TIGER RALLY 2021
• BMW R1250 RT 2022
• Suzuki M109R VZR1800 BOULEVARD 2022
• Triumph 900 TIGER RALLY 2022
• BMW R1250 RT 2023
